Gänge | 10 Gänge |
Frame | MATTS J. 26; MAT aluminium; 27.5x2.25" max. WHS; 135x9 AST; BSA BBR |
Gabel | Suntour XCR32-ATB LOR; Air; 100 STR; Lockout; 44mm fork offset; 27.5x2.4" max. WHS |
Bremse V | Shimano BR-MT200 |
Bremse H | Shimano BR-MT200 |
Bremsscheibe V | Shimano RT10; 160 mm |
Bremsscheibe H | Shimano RT10; 160 mm |
Bowden | MTK700 SP40 |
Kette | Sunrace CN11A |
Kurbel | Shimano CUES U4000; 30 |
Crank/Size | 170 mm-XS |
Tretlager | Shimano BB-UN101 68-123 |
Schaltwerk | Shimano CUES U6000; GS |
Freilauf | Shimano LG300; 11-48 ATC; 10 GER |
Pedal | VP VPE-891 |
Griff | MERIDA EXPERT JR |
Lenker | MERIDA CC; MAT aluminium; 640 WHB; 15 RHB |
H-B Stem | MERIDA CC; MAT aluminium; 31.8 DSH; 6 ASD |
H-Stem/size | 60 mm |
Steuerkopf | MERIDA M2345 |
compressor | attached |
spacer | 10mm*2 |
Nabe V | Shimano TX505; 100x9 WHF; 32 SPH; Centerlock |
Nabe H | Shimano TX505; 135x9 WHR; 32 SPH; Centerlock |
Felge | MERIDA CC; 17 IWR; MAT aluminium |
Sattel | MERIDA EXPERT JR |
Sattelklemme | MERIDA COMP QR |
Sattelstütze | MERIDA CC; MAT aluminium; 30.9 DSP; 15 SSB |
Schalthebel | Shimano CUES U6000 |
Schlauch | 26*2.2 F.V |
Reifen V | MERIDA K1227; 26x2.2"; fold |
Reifen H | MERIDA K1227; 26x2.2"; fold |
